Sanwa DM1009s Analog Insulation Resistance Tester 1000V/2000MΩ

Sanwa DM1009s Analog Insulation Resistance Tester 1000V/2000MΩ
SKU
LCT-1222617
Brand
Sanwa
Type
Multi Tester
Price
₱10,700.00
Availability
In stock

Sanwa DM1009s Analog Insulation Resistance Tester 1000V/2000MΩ

  • One-shot or continuous measurement push switch
  • DCV measurement range (DC60V)
  • Auto discharge function
  • Inner battery check range
  • Shoulder Strap

SPECIFICATIONS:
Scale(MΩ) 1～2～1000～2000MΩ
Tolerance ± 5% of reading（1st effective measurement range : written in thick print above）
±10% of reading（2nd effective measurement range : written in small type above)
ACV 600V
Tolerance Within ±5% of the max. scale value(50～60Hz sine wave)
DCV 60V
Tolerance Within ±5% of the max. scale value
Rated current 1.0～1.2mA
Battery 6LF22/6LR61(9V alkaline battery)x1
Size/Mass H144×W99×D43mm/Approx. 310g
Safety standard IEC61010 CAT.Ⅲ 600V
